Complete Dexter 10,000 lb. General Duty Axle Beam only 74" hubface by 46" spring center
Includes the brake flange, washers, and spindle nuts
This is a straight axle with spring seats underneath the axle
7 Bolt brake flange is designed for Dexter electric brake assemblies
Fits PJ Tandem Dual trailers (standard after 2015)
Main Specs:
• Construction: Steel
• Beam Finish: Painted
• Weight rating: 10,000 lb. General Duty Capacity
• Hub Face to Hub face: 74"
• Spring Center to Spring Center: 46"
• Bolt Pattern: 8 lug on 6.5"
• Brake Type: for Electric Brakes (not included)
• Lubrication: Oil Bath
Other Details:
• Axle Manufacturer: Dexter Axle
• Warranty: 5 Years Limited Warranty
• Part number: DT10GD-DX7
Additional Components:
• Axle Tube: 5" outside diameter, 0.250 wall tubing
• Spindle Size: General Duty with 7-bolt brake flange
• Hub: (not included) # 8-430-5 Drum/Hub with 5/8" wheel studs
Inside Components:
• Brakes (not included):
– 23-450 LH 12-1/4" x 3-3/8" Forward adjusting electric brake
– 23-451 RH 12-1/4" x 3-3/8" Forward adjusting electric brake
• Bearings (not included):
– Inner: 387A
– Outer: 25580
• Races (not included):
– Inner: 382A
– Outer: 25520
• Oil seal (not included): Part # 10-51 2.875" ID x 3.880" OD
