12,000 lb. Disc Brake Hub with Races & Studs

Complete hub for Dexter 12,000 lb (12K) trailer axles.

• Comes with studs and races pressed into the hub.
• Hub Pilot: 4.75"
• Bolt Pattern: 8 on 6-1/2"
• Stud size: 5/8"
• Capacity: 6,000 lbs
• This hub is standard on trailers with 12,000 lb Dexter Axles

Hub and brake rotor disc is sold separately. Click here to view the brake rotor: Dexter 12,000 lb brake rotor disc only

• Races: (included)
  • Inner: 3920
  • Outer: 28622
• Bearings: (not included)
  • Inner: 3984
  • Outer: 28682
• Oil Cap: (not included)
  • DURA CAP HD Aluminum: GT-F10-15
  • Standard plastic cap: coming soon
• Lug nut: (not included)
  • 006-209-00
  •
