3,500 lb. Axle - Electric Brakes with 5 on 5" - 89" HF 74" SC

(No reviews) Write a Review
$580.00
SKU: 110160
Weight: 152.00 LBS
Adding to cart… The item has been added
Description
Complete 3,500 lb. axle with electric brakes/drums w/ 5 studs on 5" spread • Straight axle with springs seats underneath the axle. • Found on most 77" wide PJ utility trailers. Cambered Axle Tube • 2-3/8" outside diameter Spindle Size • #84 with grease zerk Hub • #84556 #008-249-07 Drum / Hub with 1/2" wheel studs Inside components: • Brakes: – 23-26 LH 10" x 2-1/4" electric brake – 23-27 RH 10" x 2-1/4" electric brake • Bearings: – Inner: L68149 – Outer: L44649 • Races: – Inner: L68111 – Outer: L44610 • Grease seal: Part #10-19 1.719" ID x 2.565" OD Main Specs: • Weight rating: 3,500 lb capacity • Hub Face to Hub face: 89" • Spring Center to Spring Center: 74" • Bolt Pattern: 5 lug on 5" • Wheel Stud Size: 1/2" • Brake Type: Electric Brakes 10" by 2-1/4" • Lubrication: Zerk-Lube spindles with grease zerk Image: /v/vspfiles/assets/images/How to Measure Hub face3.jpg
