Complete left hand (driver side) electric brake assembly for 5,200 lb, 6,000 lb, and 7,000 lb axles.
- Simply bolts on to the axle flange with 5 bolts (not included) and hooks up the 2 electrical wires.
- These are forward Self-Adjusting brakes – require no manual adjustment.
- Works with most standard hub/drum assemblies including Dexter, Lippert (LCI), Rockwell American, and Al-KO.
- Brakes are QAI & CSA certified and pads are fully bonded (no rivets) for long life and reliability.
- E-Coated backing plates and zinc plated components provide resistance to rust and corrosion.
- Rear plastic adjuster plugs are included to cover access holes.
Main Specs:
- Brake Size: 12" Diameter x 2" wide
- Mounting Position: Left Hand (Driver's side)
- Adjust type: Forward Self-Adjusting
- Mounting Flange type: 5 bolt
- Manufacturer: Axle Teknology LLC.
- Part numbers: B12EA-21
- Warranty: Limited 1 Year
Fits common name brand axles like Dexter, AL-KO, Rockwell American, Quality and more.
Crossover part number reference chart:
|
Quality / Rockwell |
Dexter |
AL-KO |
Axis |
| Left Hand Side |
4704-LA |
23-464-00 |
1530029 |
1530029.9 |
| Right Hand Side |
4704-RA |
23-465-00 |
1530028 |
1530028.9 |
Axle Technology Quality:
Self-Adjusting Brakes Advantage:
- Standard electric brakes require the user to manually adjust the brake shoes over time. Adjustment is required to provide a consistent and efficient braking performance. Failure to complete this task results in weak brakes and failure in an emergency brake situation.
- Self-adjusting brakes are always properly aligned by adjusting automatically while driving forward, saving time and providing consistent and safer braking performance.
QAI Testing and CSA certification:
- These brake assemblies meet and exceed the requirements for the Canadian Standards Association (CSA).
- CSA certification requires a brake to stop a regulated load in a set distance and to be built to industry standards.
- These brakes have been tested by QAI for braking performance in a complete automotive setup under real-world conditions, ensuring safety and quality.
Automotive-Grade Friction Material:
- Axle Technology brings the power of automotive-grade friction material to the trailer brake market for improved stopping power and longevity.
- The friction material is fully bonded to the surface of the shoe, and the lining is custom-molded for a perfect fit that reduces cracking and crumbling.
- Tapered edges protect against mechanical lockup, which can occur when brake shoes are excessively worn or broken.
- The friction material is SAE-N certified, meaning it is environmentally safe and complies with California and Washington regulations while providing high-performance braking.
